AMH-500-P Hysteresisgraph – Advanced BH Tracer for Hard Magnetic Materials
The new powerful AMH-500-P Hysteresisgraph BH tracer is a DC automatic magnetic characterization equipment of hard magnetic materials with a bigger yoke. This permits a much higher field respect the standard one (up to +54% at higher gaps).
Other improvements:
- More suitable for samples having big size and high coercivity
- Additional thermal protections and controls on the yoke and cabinet
- More powerful power supply in the permeameter
- Finer control of the temperature of the high-T poles with special heating controller
AMH-500-P meets the International Standard IEC 60404-5 and ASTM A977 as well as the AMH-500. Measurements are performed either at room temperature or temperatures up to 220 ° with dedicated heating poles.
- Alnico
- Ferrite
- NdFeB
- SmCo
- Bonded magnets
With the additional Iron Cobalt Pole pieces the peak of magnetic field density increases up to 3.2 T with a 2.5 mm fixed gap
- Complete range of measures 2nd quadrant, 1st quadrant, hysteresis cycle, recoil curves
- Automatic or manual control of magnetizing and demagnetizing parameters for full test flexibility
- Comprehensive magnetic characterization, with automatic calculation of Br, HcJ, BHmax and all key parameters
- Advanced curve management — comparison, interpolation, and temperature extrapolation functions
- Automatic correction and compensation for pole saturation and fluxmeter drift
- Configurable unit systems: SI and CGS, mm/inch, °C/°F
- Temperature measurements up to 220 °C
- Easy-to-use software and hardware
- Wide range of accessories for any sample shape or size
Xenon is a powerful software to manage automatically the measurement and provides additional help to overcome several physical limitations; extrapolation of the curve at higher or lower temperatures, interpolation of the curve when incomplete or irregular, curve’s completion for high-coercivity magnets, etc.
This operating software maintains the overall accuracy controlling all the parameters to ensure the measurement is precise and prevents operator’s errors.
- Fluxmeters, Power supply, Heating unit and Polarity switch
- Electromagnet + poles
- Measuring coil
- PC and printer
- Dedicated software Xenon
- Reference sample, for day-to-day control
Real-time virtual help assistant for suggestions or warnings that constantly updates the status of the machine and during the measurement cycle.
Support is guaranteed via TeamViewer, Skype and through our software that allows sending, manually or scheduled technical assistance request via email.
The training is provided both during the Acceptance test in Laboratorio Elettrofisico before delivery and, upon request, at Customer’s facility.
